Radium Engineering Fuel Pump Hanger Toyota GR86/ Subrau BRZ (2022-2024) 20-1074

Fitment Information

• Compaible with the following Fuel Pumps:
  • Ti Automotive Walbro F90000267
  • Ti Automotive Walbro F90000274
  • Ti Automotive Walbro F90000285
  • Deatschwerks DW440 (brushless)
  • Fuelab 49614 (brushless)
  • Protec 11928 (brushless)
• Compatible with the following vehicle models:

  • Subaru BRZ (2022, 2023, 2024)

  • Toyota GR86 (2022, 2023, 2024)

Specifications

• 8AN ORB to 8AN Male Pump-Out Fitting
• 6AN ORB to 6AN Male Return Fitting
• Collector Box with 1-Way Fill Valve
• Venturi Jet Pump Siphon
• High Current Electrical Connections
• Anodized Fuel Level Sender Mount
• Twin Fuel Pump Compatibility
• Brushless Pump Compatibility
• Single Merged Fuel Pump Outlet
• Stainless Hardware and Clamps
• Alternative Fuel Compatibility
• New Anti-rotation Electrical Terminals

What Includes

• Integrated Check Valve Filter (-03 Stainless or -05 Microglass)
• RA-Series Fuel Pressure Regulator
• Fuel Pressure Gauge
• Heat Exchanger Filter Mount
• Aluminum Filter Bracket
• SAE Quick Connects
• Aluminum Adapter Fittings
• 8AN and -6AN PTFE Fuel Hoses
• 6AN PushLok Hose Ends
• 3/8" Fuel Return Hose
• Stainless and Aluminum Hardware


Product Description

The new Radium Engineering fuel pump hanger has been redesigned for improved fuel collection and for ease of installation. It completely replaces the factory in-tank fuel pump module and allows 1 or 2 aftermarket fuel pumps to be used. The OEM level sender is retained in order to maintain factory functionality.

PREVENTING FUEL STARVATION

The kit includes a 1-piece anodized aluminum collector box that makes installation a breeze and keeps fuel trapped around the pump inlet(s). There is a 355 LPH 1-way fill valve incorporated in the bottom of the collector that allows fuel in, but not out.
