Radium Engineering Fuel Rails GM LS9 & LSA - 20-0362

Fitment Information

• These fuel rails are compatible with the following vehicles that use the General Motors LS9/LSA V8 engines:
• Corvette ZR1 (2009-2013()

• Chevry Camaro ZL1 (2012-2015)

• Cadillac CTS-V (2009-2015)

• HSV Senature Signature (2015-2017)

• HSV Clubsport R8 (2015-2017)

• HSV Maloo R8 (2015-2017)

• HSV GTS (2013-2017)

• Equus Bass 770 (2014)

• HSV GTSR and GTSR Maloo (2017)

• HSV GTS Maloo (2014)

• HSV GTSR W1 (2017)

Specifications

• The fuel rail ports are tapped for 8AN ORB.
  • 8AN ORB Adapter Fittings

  • 8AN ORB Direct Mount Regulators

  • 8AN ORB Fuel Pulse Dampers

  • Fuel Pressure Gauge Adapters
• Appropriate fittings must be selected based on the specific application. Ample space around the fuel rail port(s) is necessary for larger accessories such as fuel pressure regulators, fuel pressure gauges, and fuel pulse dampers. To verify clearance, the dimensional drawings on the product pages can be used as a reference guide.

What's Included?

• Black Anodized Laser Etched Aluminum Fuel Rails (x2)

• Fuel Rail End Fittings, 8AN ORB Plugs (x4)

• Stainless Steel Mounting Feet (x4)

• Stainless Steel Hardware (x12)

Product Description

Each fuel rail has SIX 8AN ORB ports, 12 ports in all. Four 8AN ORB plugs are included with the rail, intended for the end ports which cannot be used due to close proximity to other components. It is up to the installer to determine what additional fittings or accessories are needed.

The fuel rails are CNC machined from 6061 aluminum, black anodized, and laser etched for a high quality surface finish.

NOTE: It is advised that the fuel rails be mocked up on the engine before adapter fittings and fuel delivery accessories are purchased. This is necessary to check clearance of surrounding engine components which may interfere with accessing some of the fuel rail ports.

The kit features polished stainless steel brackets that attach to the factory fuel rail mounting points. No vehicle modifications are required. Like the OEM fuel rails, the injector bores are 14mm ID and are compatible with factory fuel injectors. This fuel rail kit is also compatible with any aftermarket injector that is designed for fitment with the OEM fuel rail.

Additionally, these rails have provisions for the factory injector clips. This rail is compatible with all fuel types including popular alcohol mixtures such as E85.
