Radium Engineering Fuel Rails Audi R8/ Lamborghini Huracan - 20-0866

Fitment Information

• Audi R8 Gen2 Type4S

• Lamborghini Huracan LP580-2

• Lamborghini Huracan LP610-4

• Lamborghini Huracan LP640-4

• Lamborghini Huracan EVO

• Lamborghini Huracan STO

• Lamborghini Huracan Tecnica

Specifications

• PORTS AND FITTINGS

  The fuel rail ports are tapped for 8AN ORB.

  • 8AN ORB Adapter Fittings

  • 8AN ORB Direct Mount Regulators

  • 8AN ORB Fuel Pulse Dampers

  • Fuel Pressure Gauge Adapters

What Include's

• Includes the fuel rails and the mounting hardware, making it ideal for custom applications.

Product Description

Manufactured with very large .069" internal bores, the fuel rails can support all necessary engine power requirements. They are CNC machined from 6061 aluminum, anodized, and laser etched for a high quality surface finish. Each fuel rail has six 8AN ORB ports (12 in total). Like the OEM fuel rails, the injector bores are 14mm ID so factory injectors, or any equivalent aftermarket injector, can be used. As shown below, the factory injector retaining clips can be reused.

20-0866 only includes the fuel rails and the mounting hardware, making it ideal for custom applications. Extra fittings, hoses and other fuel plumbing items will be needed to complete the installation. For custom applications that demand a fuel pressure regulator and/or fuel pulse damper, a good location is on the right rear ports, as shown.

The fuel rail is compatible with all fuel types including popular alcohol mixtures such as E85.
